Mitutoyo Mechanical V-Anvil 5-Flute Micrometer, 65-85mm - 114-124

Mitutoyo Mechanical V-Anvil 5-Flute Micrometer, 65-85mm - 114-124

Features:

• Measures the outside diameter of cutting tools (such as taps, reamers, end mills) with an odd number of flutes.

• With ratchet stop for constant force.

• Supplied with setting standard.

• Non-slip grip finish (digital models).

• V-anvils with a centerline groove are available. They are useful for measuring pitch diameters of taps which have a small diameter by using single-wire method.

• With SPC output (Series 314).

• Supplied in fitted plastic case.

Technical Data:

• Graduation**: .001" or .0001", 0.01mm
• Flatness (spindle/anvil):
  Analog model: .000024” / 0.6μm, .00005” / 1.3μm
  Digital Model: .000012" / 0.3μm, .00004" / 1μm
• Spindle face: Carbide tipped
• Display*: LCD
• Battery*: SR44 (1 pc.), 938882
• Battery life*: Approx. 2.4 years under normal use

*Digital models **Analog models

Function of Digital Model:

• Zero / ABS, Data hold, Data output, Preset, inch/mm conversion (on inch/metric models only)

• Function lock, 2 Presets

• Alarm: Low voltage, Counting value composition error

Optional Accessories for Digital Model:

• 05CZA662: SPC cable with data switch (40" / 1m)
• 05CZA663: SPC cable with data switch (80" / 2m)

See all Mitutoyo V-Anvil Micrometers Series 314, 114 - 3 Flutes and 5 Flutes
