Industrial Magnetics FXR Permanent Rare-Earth Lifting Magnet for Round Material, 2650 lbs./1200 kg. Load Limit - FXR2650
Brand: Industrial Magnetics- SKU:
- FXR2650
- ID:
- 353628
| Load Limit | 2650 lbs. / 1200 kg. |
| Overall Height | 13.1" |
| Overall Length | 18.5" |
Industrial Magnetics FXR Permanent Rare-Earth Lifting Magnet for Round Material, 2650 lbs./1200 kg. Load Limit - FXR2650
These on/off permanent lifts offer strength in a lightweight, compact package. Each line of lifting magnets in the FX family of products has been specifically designed for maximum performance by user application. The size, shape and dimension of the parts you'll primarily be lifting - whether flat, curved, or circular-shaped - will determine the best FX lift magnet for you.
On all magnets in the series, the unique handle design only requires a 90° rotation to either engage or disengage the magnet (versus the 120° or even 180° required on most on/off lifting magnets), making it easy for operators to use in applications where the magnet is lifting something from inside a bin or a deep trough. The handle also features a positive lock-on/lock-off mechanism that requires the operator to manually switch between the two states. This prevents the handle from being turned only partially on, or from being accidentally bumped to the "off" position and dropping the load pre-maturely.
FXR PERMANENT LIFTING MAGNETS for Round Material
FXR - Mostly round/curved surfaces such as shafts, thick wall pipe, billets and occasional flat material
We recommend the FXR for when you’re mostly lifting round/curved surfaces such as shafts, thick walled pipe, or billet, but occasionally need to lift flat material. Specially designed pole shoes provide a deep penetrating magnetic field and part stability.
Features:
- On/Off, Rare-Earth Permanent Magnet
- On/Off handle only requires 90° rotation and locks at both on/off positions
- Durable, recessed metal name plates, not stickers
- Corrosion resistant, plated-magnet surface
- Heat resistant up to 180°F (82°C)
- 3:1 Design Factor
- 2018 ASME B30.20 BTH-1 Design Category B, Service Class 3
- Manufactured in Germany
Specifications:
| Item Number | FXR2650 |
| Working Load Limit | 2650 lbs. / 1200 kg. |
| Overall Height | 13.1" |
| Overall Length | 18.5" |
| Magnet Height | 7.5" |
| Magnet Width | 9.7" |
| Magnet Length | 18.2" |
| Handle Length | 16.1" |
| Bail Thickness | 1" |
| Bail Height | 3.5" |
| Bail Width | 2.6" |
| Weight | 280 lbs. |
