Aloris Universal Tool Holder No. 22 - DA-22
Brand: Aloris- SKU:
- DA-22
- ID:
- 113093
| Dimension A | 2-3/4" |
| Dimension E | 2" |
| Min. Bore Dim. | 4-1/4" |
| Max. Bore Length | 3-1/2" |
$479.95
Aloris Universal Tool Holder No. 22 - DA-22
- A unique design provides for many angular turning, contouring and chamfering operations.
- The cartridge has 12 indexing positions at 15° intervals.
- All holders assure proper cutting edge and clearance angles at all indexing points.
- Two-way adjustable rake for right or left hand turning with 5° cutting angle – positive stop.
- Tool steel cartridge adjusts every 15º for right or left hand turning, facing or chamfering.
- 12 positive lock positions.
- Exclusive positive lock with 2-way force holding insert down and tight against shoulder.
- Standard triangular carbide insert has 6 cutting edges.
The model #22, with its two-dovetail design, leads to a wide range of applications by permitting front and rear turning, contouring, boring and facing operations.
Dimensions (see image):
A: 2-3/4"
E: 2"
Min. Bore Dim.: 4-1/4"
Max Bore Length: 3-1/2"
