ACER 14" x 40" Precision E-Lathes
ACER High Speed Inverter Drive Engine Lathes
Features:
- HEADSTOCK: All gears are made with chromium molydenum steel and are hardened & ground to its accuracy. A forced lubrication system lubricates all running gears and bearings within the headstock.
- GEAR BOX: Unique two lever universal gear box offers a wide range of cutting capacity. All ranges can be reached by moving two levers and two dials.
- SPINDLE: 1-1/2" bored spindle is made from medium carbon steel and is induction hardened & ground to its final accuracy. It also has a two-point support with both bearings being taper roller.
- APRON: Automatic feeding and threading in apron are fully interlocked to prevent simultaneous engagement of both functions.
- TAILSTOCK: Keyed 1-7/16" diametered quill is hardened to Rockwell C 55° & ground to its inspection accuracy.
- Infinite variable speeds.
- Oil level indicator.
- 24 volts safety control circuit with Allen Bradley switches.
- Weigh in at 1,580 lbs.
- Safety overload device.
- Standard foot brake.
- Forward/stop/reverse lever.
- Half-nut engagement handle.
- 9" wide bed way with FC-30 casting iron.
- Hexagonal bed web.
- Oil lubricated leadscrew.
- Two-tone automotive paint.
Special Package Price Includes:
Package A: E-Lathe 1440V equipped with "Newall" DP700 2-Axis DRO installed in ACER Facility
Package B: E-Lathe 1440V equipped with "Newall" E70, 2-axis (Digital Readout) & C.S.S. (Constant Surface Speed) & Pre-Installation at ACER Warehouse.
Standard Accessories:
- One 6" Three Jaw Chuck
- 4-Way Tool Post
- One 8" Four Jaw Chuck
- One 10" Face Plate
- One Steady Rest (0.78"-2.15")
- Built-In Coolant System
- One Follow Rest (0.78"-1.97")
- Full Length Splash Guard
- Halogen Work Light
- Foot Brake
- Tool Box w/ Tools
- Micrometer Stop
- Chuck Guard with Emergency Stop
For more info, visit www.p65warnings.ca.gov.
| Item Number | Description | Price | Quantity |
|---|---|---|---|
| E1440V-A | ACER 14" x 40" Precision E-Lathe Package A | $ 19,995.00 | |
| E1440V | ACER 14" x 40" High Speed Inverter Drive Engine Lathe | $ 16,495.00 | |
| E1440V-P | ACER 14" x 40" High Speed Inverter Drive Engine Lathe Package B | $ 19,995.00 | |
| AAP-002B | "Aloris" Tool post & 4 Holders (#2 - BS) | $ 1,095.00 | |
| AAP-002S | "Aloris" Tool post & 6 Holders (#2 Set) | $ 1,395.00 | |
| SD30BXA-TS | "Dorian" Quick Change Tool post & 4 Holders | $ 1,395.00 | |
| AMS-002S | Micrometer Stop | $ 220.00 | |
| CAS-400 | Four Position Carriage Stop | $ 695.00 | |
| ACC-5C14 | 5C Collet Closer (Lever Type) | $ 2,195.00 | |
| ATT-002 | Taper Turning Attachment | $ 1,695.00 | |
| NEW-700 | "Newall" DP700 2-Axis DRO (8"x40" Travel) | $ 3,195.00 | |
| NEW-702 | "Newall" E70 2-Axis DRO & Constant Surface Speed | $ 3,695.00 | |
| SON-840 | "Sony" 2-Axis DRO (8" x 40" Travel) | $ 3,195.00 | |
| IF-DRO | Installation Fees for DRO | $ 595.00 | |
| IND-440 | Upgrade to 440V (3 Phase) Inverter Drive | $ 995.00 |
