Sine System Angle Plates - 77-313-5
Brand: Suburban Tool Inc.-Taft Peirce Metrology- SKU:
- 77-313-5
- ID:
- 94304
Dimensions | 3 x 3 x 2-3/4 x 1" |
Tapped Holes | (24) 1/4-20 |
$408.28
- Made in U.S.A.
- High precision, solid one-piece steel construction.
- Hardened to 58-62 Rc.
- Ground flat, square and parallel.
- 1/4" or 3/8" tapped holes allow the use of standard, readily available accessories.
- The multi-use Compound Angle Plate has several small ground vees for convenient holding of small round parts and includes 1 clamp.
- Sine system models bolt directly to sine system sine plates and compound sine plates of the same series. *) 90° conversion model. Its hole pattern duplicates that of the 6 x 6" Sine System Sine Plates allowing the Sine System 1 accessories to be bolted on. It can in turn be bolted directly to the 6 x 6" Sine Plate and 6 x 6" Compound Sine Plate, giving true 90 degree convertability. 2 side rails, 4 holddown bolts and a matching T-wrench are included.
