Mitutoyo Coolant Proof Micrometer, Range 3-4" w/ Ratchet Friction Thimble - 293-347-30
Brand: Mitutoyo- SKU:
- 293-347-30
- ID:
- 88866
| Accuracy | ± 0.0001" |
| Range | 3 - 4" / 76.2 - 101.6 mm |
| SPC Output | No |
$405.00
Mitutoyo Coolant Proof Micrometer - 293-347-30
Range: 3-4" w/ Ratchet Friction Thimble
with Dust/Water Protection Conforming to IP65 Level
FEATURES:
- IP65 protection level, enabling use in environments exposed to cutting oil, etc*
*Anti-corrosion treatment is required after use. - Measurement data output function is available with a water-resistant connection cable.
- Auto power ON/OFF function.
- Certificate of inspection* is included. (50mm/2” or less range models)
*It is not the type used to obtain calibration certificates. - With a standard bar except for 0-25mm/0-1" model.
- Supplied in fitted case. Plastic case up to 150mm/6", Wooden box over 150mm/6"
Technical Data:
| Accuracy: | Refer to the above list of specifications. |
| Resolution: | 0.001mm or .00005"/0.001mm |
| Flatness: | 0.3µm/.000012” |
| Parallelism: | 1µm/.00004” for models up to 50mm/2” 2µm/.00008” for models up to 100mm/4” 3µm/.00012” for models up to 175mm/7” 4µm/.00016” for models up to 275mm/11” 5µm/.0002” for models over 300mm/12” |
| Measuring Faces: | Carbide tipped |
| Display: | LCD |
| Battery: | SR44 (1 pc.), 938882 |
| Battery Life: | Approx. 1.2 years under normal use (8 months: over 100mm models) |
| Dust/Water Protection Level: | IP65 |
| Function: | Origin-set, Zero-setting, Automatic power on/off, Data hold, Data output, inch/mm conversion (inch/mm models) |
| Alarm: | Low voltage, Counting value composition error |
