Kent Combination Horizontal & Vertical Spindle Mills
Kent USA Combo H/V Mills offer both the capabilities of a Vertical Mill and a Horizontal Mill in one design. Changing the setup from one operation to the other is quick and simple. These mills are equipped with hard-chromed dovetail ways or hardened and ground box ways for superior wear resistance and separate motors drive the vertical spindle and horizontal spindle. Kent USA Combo H/V Mills offer both knee and bed type variants.
- 5 HP horizontal spindle motor, 9 speed ranges. 5 H.P. vertical spindle motor, 16 12” x 51” hardened and ground table top
- Saddle and knee with hardened and ground square (box) ways
- Precision ballscrews in X & Y axes
- X & Y axes driven by AC servo motor
- Precision bored and ground milling head, with super precision ABEC-7 bearings
- Meehanite® casting, with built in coolant reservoir in machine base
- Coolant system and chip tray
- Centralized automatic lubrication, with metered check-valves
Optional Accessories
- DRO System
- Air Power Drawbar (Per Spindle)
- Angle-Lock Vice
- Rotary Table (Vertical and Horizontal)
- Clamping Kit
- Chuck System
- Rustlick Coolant (1 Gal, Mixes 1:30)
